| 극의 수: | 4 | 운영 범위: | 9V~16V/9C~26V |
|---|---|---|---|
| 정격 전류 mA: | 130/70 | 자격증: | 3c |
| / 분 무부하 속도 Ｒ: | 7300 | 무부하 전류 mA: | 270/180 |
| 정격 속도 r/min: | 5500/6000 | 정격 전력 Ｗ: | 7.3/8.0 |
| 강조하다: | 4 Poles BLDC Planetary Gear Motor,Planetary Gearbox BLDC Planetary Gear Motor |
||
제품 설명
30JM30K/B2847 28mm OD Standard Gearbox BLDC Planetary Gear Motor 4 Poles
Features
1.Brushless motor built-in driver, with a positive inversion, speed control, brake (brake) function.
2.28mm OD Planetary Gearbox,
Permissible Load Range: 0.3N.m~3.0N.m
Dimensions
Brushless Motor Technical Data
| TYPE | Number of poles |
Number of phase |
Operating Range |
Rated voltage VDC |
No- load speed r/min |
No- load current mA |
Rated torque g.cm |
Rated speed r/min |
Rated current mA |
Rated power W |
|||||||||||||
| B2847-1273 | 4 | 3 | 9V~ 16V | 12 | 7300 | 270 | 130 | 5500 | 130 | 7.3 | |||||||||||||
| B2847-2473 | 4 | 3 | 9V~26V | 24 | 7300 | 180 | 130 | 6000 | 70 | 8.0 | |||||||||||||
Brushless Gear Motor Technical Data
1.B2847-1273 BLDC Motor
2.B2847-2473 BLDC Motor
Wire Diagram
PIN 1# (Blue) Brake control
PIN 2# (Orange) PWM speed regulation: Input a 20~30kHz PWM signal, and adjust the motor speed by adjusting the duty cycle.
PIN 3# (Black) Negative pole of power supply
PIN 4# (White) Forward and Reverse Rotation: Suspended steering is CCW, short circuited to ground steering is CW.
PIN 5# (Green) Feedback n=60 * F/P, where F is the feedback frequency and P is 4 pairs of motor pole pairs.
PIN 6# (Red) Positive pole of power supply
Connection line length 200mm
